Intelligent Crane

Accurate Positioning Coordinate Intelligent Crane

If you want buy this product,You can contact us via the contact details below

Intelligent Overhead & Gantry Crane coordinate positioning includes three dimensions position coordinates: lifting direction, trolley hoist traveling direction and the whole Intelligent Overhead & Gantry crane traveling direction. According to the characteristics of each direction, need different coordinate positioning device.

Hoist lifting coordinate positioning
Absolute encoder is widely used in distance detection, technology mature, lower cost. Commonly used for the lifting direction Coordinate positioning.

Hoist Traveling or lifting position coordinate
Laser ranging position is high accuracy, fast response, easy to maintain, generally used for traveling trolley travel direction or lifting direction Coordinate positioning.

Hoist and Intelligent Overhead & Gantry crane traveling
Magnetic absolute scale adopt non-contact working, can be applied to harsh operating conditions, high positioning accuracy, long positioning distance, generally applicable to the Hoist and Intelligent Overhead & Gantry crane traveling direction Coordinate positioning.

This Intelligent Overhead & Gantry crane Coordinate positioning system accuracy is up to ± 15mm error range.
