Electric Transfer Cart
Battery Powered Railway Transfer Cart
If you want buy this product,You can contact us via the contact details below
Feature
* The KPX series Electric Transfer Cart is powered by battery. The battery is installed inside the cart.
* The KPX series Electric Transfer Cart is able to run on straight railway or L-form track or S-form track or curved track.
* The KPX Electric Transfer Cart is available in inflammable and explosive environment or used as ferry car.
* The KPX Electric Transfer Cart is suitable for long distance transportation and low frequency, since its travel distance is unlimited and low requirement to the track.
Application
KPX Electric Transfer Cart can be used indoor or outdoor, widely applied in these fields, such as construction, steel plant, shipyard, chemical industry, metallurgy, foundry, new factory construction and shipbuilding and so on.
Advantage
1. Security and convenience.
2. Simple structure and comparatively low price.
3. KPX Electric Transfer Cart Can travel in curves and switches, many restrictions on travel distance of the track there is no insulation requirements, low-cost construction aspects.
No requirement for the construction of the railway.
Techncial Parameter
| Type | KPX6 | KPX10 | KPX16 | KPX25 | KPX40 | KPX63 | KPX100 | KPX160 | |
|---|---|---|---|---|---|---|---|---|---|
| Rated load (t) | 6 | 10 | 16 | 25 | 40 | 63 | 100 | 160 | |
|
Table dimensions (mm) |
Length | 3600 | 3600 | 4000 | 4500 | 5000 | 5600 | 6300 | 8000 |
| Width | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2800 | 2800 | |
| High | 550 | 550 | 580 | 650 | 700 | 850 | 900 | 1150 | |
| Running speed (m/min) | 30 | 30 | 30 | 30 | 25 | 25 | 20 | 20 | |
| Padding-bottom (mm) | 50 | 50 | 50 | 60 | 60 | 60 | 60 | 60 | |
| Wheel diameter (mm) | 300 | 300 | 350 | 400 | 500 | 600 | 600 | 600 | |
| Wheel pair C (mm) | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | |
| Wheel base A (mm) | 2000 | 2000 | 2200 | 2500 | 2800 | 3200 | 3600 | 4500 | |
| Power (Kw) | 2.2 | 2.2 | 3.7 | 3.7 | 5.5 | 7.5 | 7.5 | 7.5 | |
| Reference weight (t) | 2.2 | 3 | 3.8 | 4.8 | 6.3 | 8.9 | 10.8 | 23 | |
| Recommended the rail type | P24 YB222-63 | P38 BG183-63 | P43 GB182-63 | P50GB181-63 | |||||
| Quantity of wheel | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Wheel pressure | 2.2t | 3.3t | 5t | 7.5t | 11.5t | 18t | 27.5t | 22.8t | |
